Flat Face Hydraulic Quick Couplings(Stainless Steel) International Interchange ISO 16028 Qkps Series
QKPS Series stainless steel flat-face couplers offering superior corrosion resistance and durability. Perfect for food processing, pharmaceutical, marine, and other corrosive environments requiring ISO 16028 compatibility.
Material
Stainless Steel
Surface finish
Passivated
Application
Food processing, pharmaceutical industry, marine environments, sanitary applications, corrosive environment hydraulic systems
Flat Face CouplersSTEEL
Flat Face Couplers
FlatFaceHydraulicQuickCouplings(StainlessSteel)InternationalInterchangeISO16028QkpsSeries
QKPS Series stainless steel flat-face couplers offering superior corrosion resistance and durability. Perfect for food processing, pharmaceutical, marine, and other corrosive environments requiring ISO 16028 compatibility.
Material: Stainless Steel;
Surface Treat: Passivated;
Application: Food processing, pharmaceutical industry, marine environments, sanitary applications, corrosive environment hydraulic systems
Technical Data
Body Size (in)
Specifications
1/4", 3/8", 1/2", 3/4", 1"
Rated Pressure (Bar)
350, 300, 300, 250, 250
Key Features
Flat-face design with zero spillage
Stainless steel corrosion resistant
ISO 16028 international standard
Sanitary design suitable
Advanced sealing technology
Quick release mechanism
Passivated for hygiene
Marine-grade durability
Specifications
Series
QKPS
Design
Flat-Face Sanitary
Material
Stainless Steel
Standard
ISO 16028
Applications
Food processing
Pharmaceutical applications
Marine environments
Sanitary hydraulic systems
Corrosive environment protection
Food processing
Pharmaceutical applications
Marine environments
Sanitary hydraulic systems
Corrosive environment protection
Specification Details
| Body Size (in) | Rated Pressure (Bar) | Material | Standard Seal Material | Temperature Range (°C) |
|---|---|---|---|---|
| 1/4" | 250 | Stainless Steel | NBR (other material available on request) | -20 to +125 |
| 3/8" | 200 | Stainless Steel | NBR (other material available on request) | -20 to +125 |
| 1/2" | 200 | Stainless Steel | NBR (other material available on request) | -20 to +125 |
| 3/4" | 200 | Stainless Steel | NBR (other material available on request) | -20 to +125 |
| 1" | 200 | Stainless Steel | NBR (other material available on request) | -20 to +125 |
Nipple Female Thread / Male
| Metric | Imperial | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Part No. | Thread Size | BSPP Body Size | A Overall Length (mm) | B Exposed Length (mm) | C Hex Size (mm) | D Largest Diameter (mm) | Part No. | Thread Size | BSPP Body Size | A Overall Length (inch) | B Exposed Length (inch) | C Hex Size (inch) | D Largest Diameter (inch) |
| QKPS 02-02PF | G1/4 | 1/4" | 48 | 35 | 22 | 24 | QKPS 02-N02PF | NPT1/4 | 1/4" | 1.88 | 1.37 | 0.86 | 0.94 |
| QKPS 03-03PF | G3/8 | 3/8" | 60 | 43 | 24 | 26 | QKPS 03-N03PF | NPT3/8 | 3/8" | 2.36 | 1.69 | 0.94 | 1.02 |
| QKPS 03-04PF | G1/2 | 3/8" | 63 | 46 | 27 | 29 | QKPS 03-N04PF | NPT1/2 | 3/8" | 2.48 | 1.81 | 1.06 | 1.14 |
| QKPS 04-04PF | G1/2 | 1/2" | 70 | 53 | 32 | 35 | QKPS 04-N04PF | NPT1/2 | 1/2" | 2.77 | 2.08 | 1.25 | 1.37 |
| QKPS 04-06PF | G3/4 | 1/2" | 70 | 53 | 32 | 35 | QKPS 04-N06PF | NPT3/4 | 1/2" | 2.77 | 2.08 | 1.25 | 1.37 |
| QKPS 06-06PF | G3/4 | 3/4" | 70 | 53 | 36 | 38 | QKPS 06-N06PF | NPT3/4 | 3/4" | 2.77 | 2.08 | 1.41 | 1.51 |
| QKPS 08-08PF | G1 | 1" | 83 | 59 | 45 | 48 | QKPS 08-N08PF | NPT1 | 1" | 3.26 | 2.32 | 1.77 | 1.88 |
Couplers Female Thread / Female
| Metric | Imperial | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Part No. | Thread Size | BSPP Body Size | E Overall Length (mm) | F Hex Size (mm) | G Largest Diameter (mm) | Part No. | Thread Size | BSPP Body Size | E Overall Length (inch) | F Hex Size (inch) | G Largest Diameter (inch) |
| QKPS 02-02SF | G1/4 | 1/4" | 48 | 24 | 28 | QKPS 02-N02SF | NPT1/4 | 1/4" | 1.88 | 0.94 | 1.1 |
| QKPS 03-03SF | G3/8 | 3/8" | 65 | 27 | 32 | QKPS 03-N03SF | NPT3/8 | 3/8" | 2.55 | 1.06 | 1.25 |
| QKPS 03-04SF | G1/2 | 3/8" | 70 | 27 | 32 | QKPS 03-N04SF | NPT1/2 | 3/8" | 2.75 | 1.06 | 1.25 |
| QKPS 04-04SF | G1/2 | 1/2" | 79 | 36 | 40 | QKPS 04-N04SF | NPT1/2 | 1/2" | 3.11 | 1.41 | 1.57 |
| QKPS 04-06SF | G3/4 | 1/2" | 79 | 36 | 40 | QKPS 04-N06SF | NPT3/4 | 1/2" | 3.11 | 1.41 | 1.57 |
| QKPS 06-06SF | G3/4 | 3/4" | 79 | 36 | 41 | QKPS 06-N06SF | NPT3/4 | 3/4" | 3.11 | 1.41 | 1.63 |
| QKPS 08-08SF | G1 | 1" | 93 | 45 | 48 | QKPS 08-N08SF | NPT1 | 1" | 3.66 | 1.77 | 1.88 |
Accessories
Dust Protections
| Size | Nipple Dust Protections | Coupler Dust Protections | ||
|---|---|---|---|---|
| PVC Part No. | Aluminum Part No. | PVC Part No. | Aluminum Part No. | |
| mm / inch | Part Number | Part Number | Part Number | Part Number |
| 6.3 / 1/4 | CZT-1/4 | — | PZT-1/4 | — |
| 10 / 3/8 | CZT-3/8 | — | PZT-3/8 | — |
| 12.5 / 1/2 | CZT-1/2 | — | PZT-1/2 | — |
| 16 / 5/8 | — | — | — | — |
| 20 / 3/4 | CZT-3/4 | — | PZT-3/4 | — |
| 25 / 1 | CZT-1 | — | PZT-1 | — |
