Gear Pumps
Torque Cast Iron Gear Pump
Hydronex / Gear Pumps
SERIES
Gear Pumps
Torque Hydraulic Gear Pump - 0P Series
Torque Hydraulic Gear pumps 0P series are aluminum body gear pumps with high efficiency and long use life. They are designed with special aluminum alloys and covers are made of high grade cast iron to avoid deformation at high pressure.
Request a quoteTorque Hydraulic Gear Pump - 0P Series Specifications
| Pump type | Theoretical Displacement | Nominal Delivery at 1450 rev / min | Maximum Pressure | Max speed at max Pressure rev/ min. | Min. Speed at max Continuous Pressure rev / min. | |||
|---|---|---|---|---|---|---|---|---|
| in3 / rev | cm3 / rev | Imp gal/ min | l / min | psi | bar | |||
| 1003 | 0.08 | 1.23 | 0.26 | 1.2 | 3000 | 207 | 4000 | 500 |
| 1004 | 0.1 | 1.64 | 0.39 | 1.8 | 3000 | 207 | 4000 | 500 |
| 1006 | 0.13 | 2.18 | 0.56 | 2.5 | 3000 | 207 | 4000 | 500 |
| 1008 | 0.18 | 2.85 | 0.75 | 3.4 | 3000 | 207 | 4000 | 500 |
| 1011 | 0.23 | 3.81 | 1.06 | 4.8 | 3000 | 207 | 4000 | 500 |
| 1013 | 0.27 | 4.46 | 1.28 | 5.8 | 3000 | 207 | 4000 | 500 |
| 1015 | 0.31 | 5.14 | 1.5 | 6.8 | 3000 | 207 | 4000 | 600 |
Dimensional Data
Key Features
High efficiency
Low noise
Value proposition quality/price ratio
Technical specifications and long service life
Specifications
Series use
The 0P series of hydraulic gear pumps are designed for industrial use.
Motor horsepower
3 HP
Maximum continuous pressure
207 bar
Phase
Single phase
Maximum flow rate
500 LPM
Nominal displacement
6.8 Liter
Material
aluminum body
