Gear Pumps
Torque Cast Iron Gear Pump
Hydronex / Gear Pumps
SERIES
Gear Pumps
Torque Hydraulic Gear Pump-2P Series
Torque Hydraulic Gear pumps 2P series are aluminum body gear pumps with high efficiency and long use life. They are designed with special aluminum alloys and covers are made of high grade cast iron to avoid deformation at high pressure.
Request a quoteTORQUE HYDRAULIC GEAR PUMP - 2P SERIES SPECIFICATIONS
| Model No. | Theoretical Displacement | Nominal Delivery at 1450 rev / min | rated pressure (bar) | Max speed at max Pressure rev / min | |||
|---|---|---|---|---|---|---|---|
| in3/rev | cm3/rev | gal / min | l / min | rated | max | ||
| 1050 | 1.02 | 16.67 | 5 | 22.7 | 200 | 250 | 3000 |
| 1070 | 1.39 | 22.73 | 8.45 | 32 | 200 | 250 | 3000 |
| 1090 | 1.76 | 28.79 | 10.83 | 41 | 200 | 250 | 3000 |
| 1105 | 2.03 | 33.74 | 12.6 | 47.7 | 200 | 250 | 3000 |
| 1120 | 2.31 | 37.88 | 14.39 | 54.5 | 200 | 250 | 3000 |
| 1146 | 2.78 | 45.68 | 17.56 | 66.5 | 200 | 250 | 3000 |
| 1158 | 3.01 | 49.4 | 18.96 | 71.8 | 200 | 250 | 3000 |
| 1190 | 3.62 | 59.14 | 22.49 | 85.16 | 200 | 250 | 3000 |
| 1220 | 4.07 | 66.67 | 26.41 | 100 | 200 | 250 | 3000 |
Dimensional Data
Key Features
High efficiency
Low noise
Value proposition quality/price ratio
Technical specifications and long service life
Specifications
Body
aluminum body gear pumps
Efficiency
High efficiency
Service life
Long use life
Alloys
Special aluminum alloys
Covers
High grade cast iron
Protection
Avoid deformation at high pressure
