Torque Hydraulic Gear Pump - 1P Series
Torque Hydraulic Gear pumps 1P series are aluminum body gear pumps with high efficiency and long use life. They are designed with special aluminum alloys and covers are made of high grade cast iron to avoid deformation at high pressure.
Request a quoteTorque Hydraulic Gear Pump - 1P Series Specifications
| Model No. | Theoretical Displacement | Nominal Delivery at 1450 rev / min | rated pressure (bar) | Max speed at max Pressure rev/ min | |||
|---|---|---|---|---|---|---|---|
| in3/rev | cm3/rev | Imp gal/ min | l / min | rated | max | ||
| 1017 | 0.31 | 5.14 | 1.7 | 7.7 | 200 | 250 | 3000 |
| 1020 | 0.43 | 7.03 | 2 | 9.1 | 200 | 250 | 3000 |
| 1028 | 0.58 | 9.46 | 2.8 | 12.7 | 200 | 250 | 3000 |
| 1036 | 0.73 | 11.9 | 3.6 | 16.4 | 200 | 250 | 3000 |
| 1044 | 0.88 | 14.33 | 4.4 | 20 | 200 | 250 | 3000 |
| 1052 | 1.02 | 16.77 | 5.2 | 23.6 | 200 | 250 | 3000 |
| 1060 | 1.17 | 19.22 | 6 | 27.3 | 200 | 250 | 3000 |
| 1072 | 1.4 | 22.84 | 7.2 | 32.7 | 160 | 250 | 2500 |
| 1090 | 1.72 | 28.12 | 9 | 40.9 | 160 | 250 | 2000 |
Dimensional Data
Key Features
Maximum working pressure: 200 bar
Speed: 1440 rpm
Temperature: 250 degree Celsius
Shaft diameter: 3/4 inch
Motor power: 2 HP
Here are some 1P hydraulic gear pumps:
Boss Hydraulic Gear Pump 1P BHP 28: 13.1 Lpm
Plain Shaft 1P Series Dowty Gear Pump: 200 Bar
Dowty 1P 3028 CPSTB Hydraulic Gear Pump: 207 Bar, 12.7 Lpm
Dowty Gear Pump 1P 4017: AC Powered, 207
Hydrostar Hydraulic Gear Pump 1P Series: AC Powered, Electric
Specifications
Maximum working pressure
200 bar
Speed
1440 rpm
Temperature
250 degree Celsius
Shaft diameter
3/4 inch
Motor power
2 HP
