Thread Locked Type Hydraulic Couplings(Steel) Ksg Series
The KSG Series Thread Locked Type Hydraulic Couplings feature a unique panel-mount flange coupler body designed for bulkhead and panel installation. Combined with a standard threaded nipple, the KSG series provides a secure, permanent-body connection point for hydraulic systems requiring fixed mounting.
Material
Carbon Steel
Surface finish
Zinc Plated
Application
Panel mounting, bulkhead installation, fixed-point hydraulic systems
Threaded CouplersSERIES
Threaded Couplers
ThreadLockedTypeHydraulicCouplings(Steel)KsgSeries
The KSG Series Thread Locked Type Hydraulic Couplings feature a unique panel-mount flange coupler body designed for bulkhead and panel installation. Combined with a standard threaded nipple, the KSG series provides a secure, permanent-body connection point for hydraulic systems requiring fixed mounting.
Material: Carbon Steel;
Surface Treat: Zinc Plated;
Application: Panel mounting, bulkhead installation, fixed-point hydraulic systems
Technical Data
Body Size (in)
Specifications
1/4", 3/8", 1/2", 3/4", 1"
Rated Pressure (Bar)
350, 300, 300, 250, 250
Key Features
Connexion by screwing together the two parts
Disconnexion by unscrewing the two parts
Shut off by poppet valve
Connectable under residual pressure
Disconnexion under residual pressure
Interchangeability according to Faster internal Standards
Specifications
Standard
ISO 7241-2
Body Material
Carbon Steel
Seal Material
NBR
Surface Treatment
Zinc Plated
Technical Specifications
- High grade carbon steel with heat treated wear parts
- NBR
- Backup ring in PTFE
- -25°C to +125°C (-13°F to +257°F)
- According to ISO 7241-2
Applications
Bulkhead and panel mounting
Mobile hydraulic equipment
Fixed hydraulic power units
Industrial machine tools
Bulkhead and panel mounting
Mobile hydraulic equipment
Fixed hydraulic power units
Industrial machine tools
Male
| Part No. | Thread Size | Overall Length (mm) | Hex Size (mm) | Largest Diameter (mm) |
|---|---|---|---|---|
| KSG-06PF | G3/4 | 78 | 33 | 114 |
| KSG-08PF | G1 | 82 | 40 | 114 |
Female
| Part No. | Thread Size | Overall Length (mm) | Hex Size (mm) | Largest Diameter (mm) |
|---|---|---|---|---|
| KSG-06SF | G3/4 | 78 | 46 | 52 |
| KSG-08SF | G1 | 83 | 55 | 63 |
Specification Details
| Body Size (in) | Rated Pressure (Bar) | Flow Rate (L) | Material | Standard Seal Material | Temperature Range (°C) |
|---|---|---|---|---|---|
| 3/4" | 350 | 32 | Carbon Steel | NBR | -20°C to +125°C |
| 1" | 300 | 42 | Carbon Steel | NBR | -20°C to +125°C |
Performance Specifications
| Size (mm) | Size (in.) | Working Pressure (MPa/PSI) | Flow Rate (l/min / GPM) | Burst Pressure 1 (MPa/PSI) | Burst Pressure 2 (MPa/PSI) | Burst Pressure 3 (MPa/PSI) |
|---|---|---|---|---|---|---|
| 20 | 3/4" | 35 (5000) | 32 (120) | 130 (18850) | 110 (15950) | 130 (18850) |
| 25 | 1" | 30 (4350) | 42 (160) | 90 (13050) | 120 (17400) | 130 (18850) |
